ARCCAPTAIN MIG250 - Operation Control and Instructions; Panel Instruction

5
Enclosure class IP 21S
Power factor COSφ 0.72
Insulation class H
Standard ANSI/NEMA/IEC 60974-1
Noise db
＜70
Dimension inch 20.3x8.1x15.2
Weight kg/lb 20.5lb
Applicable electrode/wire inch
1/16”-1/8”
0.023”/0.030”/0.035”
1/16”-5/32””
0.023”/0.030”/0.035”/0.040”
Figure 1 Size
3. OPERATION CONTROL AND INSTRUCTIONS
3.1 Panel Instruction
Part Picture
