ARCCAPTAIN MIG250 - Operation for Spool Gun; Set up Spool Gun

21
• Keep wire and liner clean. Do not use rusty wire.
•
Sharp bends or kinks in the welding cable should be avoided
• ONLY use MIG solid welding wire.
•
MIG Welding parameters table
（
for reference only
）
6. Operation for Spool gun
! WARINING DO NOT set up without SWITCH OFF !
6.1 Set Up Spool gun
! WARINING BEWARE OF ELECTRIC SHOCK!
Description Picture

Pull the Nozzle to remove it. Unscrew the Contact Tip
counterclockwise and remove.
Figure 28
 Open Latch and remove Cover.
note:
To prevent unraveling, leave wire secured to Spool.
Figure 29
Figure 27
