Argo Aurora 800 - 1.6 Aurora 8 x8 (2019 MY) Vehicle Matrix

5
SECTION 1
GENERAL INFORMATION
Model Aurora 800 Aurora 800 SX
Aurora 800 SX
Hunt Master
Aurora 800
Limited
Aurora 950 SX
Engine Kohler (30 hp) EFI V-twin 4 cycle, liquid cooled
Briggs 40HP Twin EFI
fan cooled
Transmission (ADMIRAL) Forward, neutral and reverse with high/low range
Clutch Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission
Fuel Capacity 27 L (7.1 U.S Gal.)
Steering/Brakes Argo Progressive Steering (APS) Hydraulic steering disc brakes with hydraulic disc stopping brakes
Drive Chains Double RC 50 & Single RC 60 Roller chain
Electrical 30 Ah(10H-R) Regular Charge Current (Amp) 3.C.C.A. @ 0F (-18C) 400
30 Ah(10H-R) Regular
Charge Current (Amp)
3.C.C.A. @ 0F (-18C)
400
Load
Capacity
Land 1010 lbs. (459 kg) 925lbs. (420 kg) 925lbs. (420 kg) 950lbs. (432 kg) 925lbs.(420kg)
Water 710 lbs (323 kg) 625lbs (284 kg) 625lbs (284 kg) 650lbs (295 kg) 625lbs. (284kg)
Seating
Capacity
Land 4 persons
Water 4 persons
Shipping Weight 1540 lbs (700 kg) 1625 lbs (739 kg) 1625lbs (739 kg) 1600 lbs (727 kg) 1625lbs (739kg).
Accessory
Brake Cooling No No No No No
Brake lights Yes Yes Yes Yes Yes
Brushguard No Yes Yes Yes Yes
Drive Belt 127-137HD 127-137HD 127-137HD 127-137HD 127-159HD
Tires 25"XT 25"XT 25"XT 25"XT 25"XT
Rims Steel Offset Steel Bead Lock Steel Bead Lock
Aluminum Bead
Lock
Steel Bead Lock
Winch No 3500 lb. 3500 lb. 3500 lb. 3500 lb.
Alternator Output 40 AMPS 40 AMPS 40 AMPS 40 AMPS 50 AMPS
ROPS No No No No No
Cargo Liner No No No No No
Bearing Extensions Yes Yes Yes Yes Yes
Hood Extraction Fan No No No No Yes
Hitch Capacity Draw
Bar Pull
N / LBS
4448/1000
N/ LBS
4448/1000
N / LBS
4448/1000
N / LBS
4448/1000
N / LBS
4448/1000
Hitch Capacity Vertical
Tongue Load
N / LBS 445/100 N / LBS 445/100 N / LBS 445/100 N / LBS 445/100 N / LBS 445/100
* Speed is 20% less with 34-200-8.1
** Load capacity in water is 100lbs. less if equipped with optional 24x10.00-8NHS tires.
1.6 Aurora 8x8 (2019MY) VEHICLE MATRIX
