SECTION 11
ACCESSORY INFORMATION
that the vehicle be reversed on the truck or trailer so that
the front of the Argo faces to the rear. The windshield
should be folded down and secured in place using a rope
or a tie down strap.
Operating the Argo for extended periods in high ambi-
ent temperatures with the windshield in the folded down
position may restrict hot air ow from the engine com-
partment which could lead to engine overheating and
heat build-up in the windshield frame and glass. Use
caution when operating the vehicle with the windshield
folded down to avoid overheating in warm temperatures.
The following decal should be attached to the inside of the
windshield:
DANGER
!
Engine exhaust fumes are poisonous and
can cause illness or death if inhaled. Allow
for adequate ventilation in the passenger
compartment when a top is installed.
Les gaz d'échappement sont nocifs. Les inhaler
peut causer la maladie ou la mort. Assurez-vous
d'une bonne ventilation du compartiment des
passagers quand un toit est installé.
If this decal is not attached to the windshield, contact your
Argo retailer for a free-of-charge replacement. The part num-
ber is 126-84.
11.15 CONVERTIBLE TOP
The convertible top provides protection from the elements for
theoccupantsandoerstheoptionofrollinguporremoving
the side doors, rear door and rear side panels while leaving
the overhead portion in place.
Never fold the clear plastic windows; always roll them
up to store them in place on the top assembly or remove
them.
To fold the convertible top for storage, unzip the side and
rear doors and the side panels, lay them aside and unsnap the
domes along the front of the roof panel from the windshield
frame. Fold the aluminum top frames together and roll the
overhead panel around the frames loosely. Then, roll the
window panels around the top material so the boot will cover
the complete assembly for protection.
The convertible top assembly is not designed to withstand
the turbulence created while transporting the vehicle
with the top assembled in the ‘up’ position. Fold the
top down and secure it properly to the vehicle bodyor
remove it from the vehicle for high speed transportation.
Hearing protection is strongly advised when operating
the vehicle equipped with any convertible top assembly.
The following decal should be attached to the inside of the
windshield:
DANGER
!
Engine exhaust fumes are poisonous and
can cause illness or death if inhaled. Allow
for adequate ventilation in the passenger
compartment when a top is installed.
Les gaz d'échappement sont nocifs. Les inhaler
peut causer la maladie ou la mort. Assurez-vous
d'une bonne ventilation du compartiment des
passagers quand un toit est installé.
If this decal is not attached to the windshield, contact your
Argo retailer for a free-of-charge replacement. The part num-
ber is 126-84.
11.16 ALTERNATOR ACCESSORY - 2019MY Aurora
Vehicles Only
The externally mounted, belt driven, 40 amp alternator is
recommended when electrical accessories such as a winch
are added to the vehicle.
ChecktheV-belttensionfrequentlytobesurebeltdeection
is no more than 1/8" or 3 mm with approximately 6 lbs. or 3
kgs of force applied to the belt, halfway between the pulleys.
Adjust the belt tension as necessary. Failure to do so will
reduce the charge rate and lead to battery failure.
11.17 SNOW PLOW ACCESSORY
The snow plow assembly attaches to the front of the Argo
at two mounting brackets that bolt to the front axle bearing
extension housings. The plow blade is raised and lowered by
operating the power winch in and out.
