Connections
Bringing it all together
Connections18
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
Connecting the Set-Top Box to a TV Set
You can connect the set-top box to your TV by using the scart socket or HDMI input. Use a scart or HDMI cable to
connect the set-top box to your TV.
The set-top box gives RGB or CVBS output from scart or high definition quality from HDMI output.
Antenna Connection
This illustration shows how to connect an antenna.
Use ANTENNA IN to connect to an antenna system.
Fig 5.
Fig 6.
