28 Tensor
Programming of the end positions, set value inputs and actual value outputs:
Set-up operation has to be active
Approach end position
Save end position
Approach end position
Save end position
Select values 
0 mA 4 mA 20 mA X mA
Save value
Select values 
0 mA 4 mA 20 mA X mA
Save value
Select values 
0 mA 4 mA 20 mA X mA
Save value
Select values 
0 mA 4 mA 20 mA X mA
Save value
** Display analogous to set point default
**
**
**
