Four-Post Rack Mount Parts for 4-slot and 8-slot Chassis Appendix B: Parts List
Figure B-2: Four-Post rack mount parts for the 4- and 8-slot chassis
1 Front brackets (DCS-7504N
only)
4 Left shelf 7 M6 hex nuts
2 Front brackets (DCS-7508N
only)
5 Right shelf 8 M6x16 pan-head Phillips
screws
3 Shelf support 6 M6 cage nuts 9 Back brackets (not needed for
racks with threaded holes)
