Quick Start Guide: 7500N Series Modular Switches 59
Appendix D
Rear Panel
This appendix displays the rear panel of all switches covered by this guide.
Figure D-1: DCS-7504N rear panel (fully populated)
1 Fabric module screw 4 Chassis ground 7 Ground
2 Fabric module ejector handle 5 PSU 8 Ejector button
3 Fabric module status LEDs 6 Release lever 9 Status LEDs
