Appendix B: Parts List Four-Post Rack Mount Parts for 4-slot and 8-slot Chassis
Quick Start Guide: 7500N Series Modular Switches 51
B.3 Four-Post Rack Mount Parts for 4-slot and 8-slot Chassis
The following sections list the parts provided in the accessory kit for four-post rack mount installations
of the 4- and 8-slot chassis.
Table B-4 Four-Post rack mount parts for the 4- and 8-slot chassis
1. Quantities in parentheses “()” are for the 7508N where the quantities differ from the 7504N.
Quantity
1
Description
2 Front brackets.
4 Shelf supports.
2 Back brackets.
1 Left shelf.
1 Right shelf.
11 (17) M6X16 pan-head Phillips screws.
7 (13) M6 Hex Nuts.
3 (9) M6 Cage Nut Square Hole Racks.
5 M5 Hex Nuts.
11 (17) M5 pan-head Phillips screws.
5 #12-24 Hex Nuts.
11 (17) #12-24 pan-head Phillips screws.
5 #10-32 Hex Nuts.
11 (17) #10-32 pan-head Phillips screws.
1 Adjustable Wrench
