Aritech 2X Series User Manual

Chapter 3: Configuration and commissioning
2X Series Installation Manual 85
Group_n
Configures the output group number
Class
Configures the output wiring configuration (Class A or Class B)
Con
trol Enables or disables an output
[BLANK]
Output description
UKSB
Configures the output group activation when the UK school bell activates
To configure a control panel output:
1. Select Field setup from the Main menu.
2. Select Panel I/O configuration.
3. Select Panel outputs, and then select the corresponding output.
4. Select the output type.
See Table 48 below for a list of available output types. The default setting for
all outputs is SND (sounder output).
5. Assign the output to an output group.
See “Output groups” on page 86 for more information on output groups.
6. Select the output Class (Class A or Class B).
The default setting is Class B.
7. Press F4 (Enter), and then press F1 (Back).
8. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Configurable output types are shown in the table below.
Table 48: Configurable output types
Type
Description
SND (default)
Select this option for a sounder output
FR
Select this option for a fire routing output
FP
Select this option for a fire protection output
PRG
Select this option for program options (see below)
EXTIN
Select this option for an extinguishing output
ALARM
Select this option for an output that activates when the control panel is in
alarm status
FAULT
Select this option for an output that activates when the control panel is in
fault status
TEST
Select this option for an output that activates when the control panel is in
test status
DIS
Select this option for an output that activates when the control panel is in
disable status

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
