Aritech 2X Series User Manual

Chapter 3: Configuration and commissioning
86 2X Series Installation Manual
To enable or disable a control panel output:
1. Select Field setup from the Main menu.
2. Select Panel I/O configuration.
3. Select Outputs, and then select the output to be enabled or disabled.
Configurable outputs are listed as OUT1, OUT2, etc, the supervised alarm
output is listed as ALM_O, and the supervised fault output is listed as FLT_O.
4. In the Control option, select ENB (enable), DIS (disable), DIS_D (disable in
day mode), or DIS_N (disable in night mode).
5. Press F4 (Enter), and then press F1 (Back).
6. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Note: At the installer level, changes to the configuration of a Class A output are
applied to all output pairs used to create the Class A output (OUT1/OUT2, etc.).
This includes enable/disable configuration options. For example, if the OUT1
type is changed to PRG and Group-n changed to 5, then the configuration of the
paired OUT2 is updated automatically to match these settings.
Output groups
Select the Output groups option to configure the control panel output groups.
Control panel outputs must be assigned to output groups for activation.
An output group is a collection of outputs of the same type that activate and
deactivate at the same time (they are commanded simultaneously). Output
groups are identified by the output group number.
Outputs are assigned to the default output groups during autosetup (see
“Autosetup” on page 73).
Up to 300 sounder, fire routing, fire protection, extinguishing, and program output
groups can be configured (depending on group type).
Sounder output groups, fire routing output groups, and fire protection output
groups are controlled (and their status indicated) by the corresponding sounder,
fire routing, and fire protection buttons and LEDs on the front of the control panel.
Program output groups have no associated buttons or LEDs on the front of the
control panel but their status is displayed on the LCD.
The default control panel output groups are shown below.
Note: This option is not available on repeater panels.
Table 49: Default output groups
Group number
Type Description
1
SND Sounder and supervised outputs.
301
PRG Nonsupervised relay outputs. These outputs are assigned
to this group during autosetup.

Aritech 2X Series Specifications

General

Certifications	EN54-2, EN54-4
Power Supply	230V AC, 50Hz
Battery Capacity	7Ah
Current Consumption	Standby: 50mA
Humidity Range	Up to 95% RH, non-condensing
