EXTIN Extinguishing device outputs. [1]
FR Fire routing outputs. This group is only available on
control panels with the corresponding fire routing controls.
FP Fire protection outputs. This group is only available on
control panels with the corresponding fire protection
controls.
ALARM [2] Outputs activated when the control panel is in alarm
status.
FAULT [2] Outputs activated when the control panel is in fault status.
DIS [2] Outputs activated when the control panel is in disable
status.
TEST [2] Outputs activated when the control panel is in test status.
Extinguishing output groups are only activated with EN 54 type C alarm confirmation.
[2] These output groups are not configurable.
Configurable options for output groups are shown below.
Table 50: Configurable options for output groups
Configures the output group number
Configures the output group type
Enables or disables the output group
Output description
To configure a default output group:
1. Select Field setup from the Main menu, and then select Output groups.
2. Select Output groups.
A list of the available output groups is displayed. Press F3 (Search) to search
by group number. Press F4 (Delete) to delete an output group.
3. Select the output group to configure.
You cannot change the group number or output group type for a default
output group.
4. In the Control option, select ENB (enable), DIS (disable), DIS_D (disable in
day mode), or DIS_N (disable in night mode).
5. Enter a brief text description for the output group.
6. Press F4 (Enter), and then press F1 (Back).
7. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
