Arkray Glucocard Shine - Meter Display Symbols and Indicators

12 www.arkrayusa.com
GLUCOCARDShineBloodGlucoseMeterDisplay
Test results: test results displaying panel
Batterysymbol:indicates meter battery is running low and
needs to be replaced
mem: appears when test results stored in the memory are
displayed
alarm: appears when the post-meal alarm has been set
check: appears when test results have not been saved
Hypoglycemiasymbol:appears when the test result is
below the hypoglycemic level
Mutesymbol:appears only when the sound is set to OFF
Post-meal test flag: appears during post-meal testing and
when post-meal test results are displayed
Month/Day/Hour/Minute
Temperaturesymbol:displays recorded temperature when
blood glucose levels are tested
Bloodinsertionsymbol:indicates meter is ready for the
application of a drop of blood or control solution
Decimalpoint:appears when the blood glucose measuring
unit is set to mmol/L
mg/dL, mmol/L: unit for measuring blood glucose
10
12
1
2
3
4
5
6
7
8
9
11
13
1
12
2 3
4
5
6
78
9
13
10
11
Note: The unit of measurement is fixed in mg/dL and it
cannot be changed to mmol/L by the user.
