1508685 Rev D CHP Max Element Management Modules CHP-CMM, CMM-1, SMM, and SMM-1 6-21
Figure 6.13
Shelf Command
Listing Example
➤ To set the CHP trap destination address
11. Type destadd followed by the IP address and port number of the SNMP manager
and then press Enter for each desired trap destination to identify where the traps
will be sent.
For example, the following command sends SNMP traps to an IP address of
155.226.60.12 and port number of 162.
12. Type reset and press Enter to reset the chassis containing the SMM.
13. After being reset, the CHP system will be ready to communicate on the configured
subnet.
➤ To set the SMM to its default IP address
14. If the SMM IP address that was entered is not known, or is not configured correctly
and communications cannot be established with the SMM, the SMM can be changed
back to the default SMM IP address (192.168.1.1) by performing the following:
a. Press upward on the latch release on the front panel and slide the module out
the front of the chassis.
Note Only perform Step 11 if you are using an SNMP manager.
Shelf Index Number — Used with the shelfrem command to remove a shelf.
Type “shelfrem 2” to remove the shelf with index number 2 that corresponds to a CMM address
CMM Address — Address of CMM or SMM module.
Modules manufactured on or after 7-1-2005 have a 5 digit CMM Address label on the CMM or SMM
module.
destadd 155.226.60.12:162
IP Port
To Next Page
