Arris Touchstone DG3270 - Patterns: Normal Operation (WAN); Cable Modem Startup Sequence

Chapter 5: Operate the Data Gateway
Mode Ethernet (LEDs on
rear panel connector)
2.4G Wi-
Fi / 5G Wi-Fi
MoCA
Amber/Green LED Flash
= Computer activity
Both LEDs Off =
Computer not connected
Off = MoCA disabled
or no MoCA network
device attached
No AC power Off Off Off
Firmware
upgrade
(normal operation) (normal operation) (normal operation)
Patterns: normal operation (WAN)
Table 2: Light patterns during normal operation
Mode Power US/DS Online
AC power
good
On On = Connected
to the Internet
Flash = Not connected
to the Internet
On = Internet available
Off = Internet not available
No AC power Off Off Off
Firmware
upgrade
On Flash On
Cable modem startup sequence
Table 3: Light patterns that occur during cable modem startup
US/DS Online Description
Slow flash (1/second) Off Downstream acquisition in progress
On (until upstream
acquisition starts)
Off Downstream acquisition completed
Fast flash (3/second) Off Upstream acquisition in progress
On Slow flash (during
acquisition)
On (when modem
IP address obtained)
Upstream acquisition
completed, ready for service
Touchstone DG3270 Data Gateway User Guide STANDARD Revision 1.1 28
