30
8. Pull the lever(6) out of the notch for
handlebar height adjustment and flip the
guide rail to the front.
9. Pull off the cotter pin (7) and remove the
safety pin (8).
10. Insert the safety pin(8) through one of the
borings and secure the safety pin on the
other side with the cotter pin(7).
11. Lock the crank(1) for the height adjustment
with the spring cotter(2) on the guide rail.
Loading
Use suitable ramps for loading that
– can carry the empty weight of the device +
200 kg.
– are wider than the device.
– have a slip-free surface.
Notice
Risk of damage due to incorrect fastening of
straps.
► Fasten the straps only at the points
shown in the figure.
► Do not overtighten the straps.
1. Put the device in front of the ramps and
make sure that the ramps
– are as wide as the wheel gauge of the
device.
– are tightly secured to the platform.
– are not steeper than 15°.
2. Carefully drive the device via the ramps
onto the platform.
3. Observe the instructions in chapter
Switching off and parking.
4. Secure the device against rolling, sliding
and tilting. Use straps that support the
weight of the device.
5. Secure the device with belts to the frame
elements that can hold the weight.
