AS MOTOR AS 62 E-Allmaher - Transmission; Checking the Drive; Checking the Parking Brake

37
Additional inspection for backpack battery
Check that the backpack battery engages cor-
rectly on the adapter plate when inserted.
Check that the plug of the backpack battery
can be fully inserted into the connection socket
on the engine and is securely held in place.
Contact an authorised service centre if this is
not the case.
Transmission
The transmission is maintenance-free and
filled with oil that is supposed to last the entire
service life of the device. Make sure that there
are no leaks or damages.
Checking the drive
1. Place the device on a surface with a good
grip (e.g. concrete or asphalt).
2. Switch off the engine.
3. Actuate the drive.
4. Try to pull the device backwards.
If the rear wheels block, the drive is set cor-
rectly. If you can pull the device, the drive must
be readjusted.
1
Re-adjusting the drive
Turn the adjusting screw (1) at the drive so that
the wheels lock, while the drive is actuated,
when the device is pulled. If there is no im-
provement after the adjustment, have the
device checked by an authorised service
centre.
Checking the parking brake
AS 63 E-Allmäher
Warning
If the parking brake is incorrectly adjusted,
the device can roll away.
► Make sure that the parking brake is al-
ways functioning properly.
1. Place the device on a surface with a good
grip (e.g. concrete or asphalt).
2. Release the drive lever and the brake
lever.
ð Parking brake is actuated.
3. Try to pull the device backwards.
If the left rear wheel locks, the parking brake is
set correctly. If the device can be pushed, the
parking brake must be readjusted by an au-
thorised service centre.
