Ascon Tecnologic - X34 - OPERATING INSTRUCTIONS - PAG. 21
7. PROGRAMMABLE PARAMETERS TABLE
Here below is a description of all the parameters available on the instrument. Some of them may not be present, either due
to the fact they depend on the type of instrument or because they are automatically disabled as unnecessary.
Note: Those parameters marked with (#) character can be applied to models with Real Time Clock only.
]SP Group - Set Point parameters
Parameter Description Range Def. Note
1
S.LS
Minimum Set Point -99.9 ÷ S.HS -50.0
2
S.HS
Maximum Set Point S.LS ÷ 999 99.9
3
SP
Set Point S.LS ÷ S.HS 0.0
4
SPE
Eco Set Point SP ÷ S.HS 2.0
5
SPH
“Turbo” Set Point (or independent Heating Set Point in mode HC) S.LS ÷ SP -2.0
]in Group - Inputs parameters
Parameter Description Range Def. Note
6
i.SE
Probes Type
Pt PTC
nt NTC
P1 Pt1000
nt
7
i.uP
Unit of measurement and resolution
(decimal point)
C0 °C with 1° res.
F0 °F with 1° res.
C1 °C with 0.1° res.
F1 °F with 0.1° res.
C1
8
i.Ft
Measurement filter
oF Filter disabled
0.1 ÷ 20.0 s
2.0
9
i.C1
Pr1 Probe Calibration -30.0 ÷ 30.0 °C/°F 0.0
10
i.C2
Pr2 Probe Calibration -30.0 ÷ 30.0 °C/°F 0.0
11
i.C3
Pr3 Probe Calibration -30.0 ÷ 30.0 °C/°F 0.0
12
i.C4
Pr4 Probe Calibration -30.0 ÷ 30.0 °C/°F 0.0
13
i.CU
Measure offset on the display -30.0 ÷ 30.0 °C/°F 0.0
14
i.P2
Pr2 input function
oF No function
EP Evaporator 1
Au Aux
cd Condenser
2E Evaporator 2
EP
15
i.P3
Pr3 input function
oF No function
EP Evaporator 1
Au Aux
cd Condenser
2E Evaporator 2
dG Digital input
oF
16
i.P4
Pr4 input function oF
17
i.1F
Function and function logic of digital input DI1
0 No function
1 Door open
2 Door open with fan stop
3 Door open with fan and compressor stop
4 External “AL” alarm
5 External “AL” alarm with deactivation of control outputs
6 Selection of active Set Point (SP-SPE)
7 Switch on/ off (Stand - by)
8 “Turbo” cycle activation
9 Remote command of AUX output
10 Disable recording of HACCP alarms
11 Reset of HACCP alarms
12 External “PrA” alarm
13 External “HP” alarm
14 External “LP” alarm
15 Forcing events Switch ON/OFF (Stand - by)
16 Start Defrost
17 Stop Defrost
0
18
i.1t
Delay in acquiring digital input DI1
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
19
i.2F
Function and function logic of digital input DI2
See (17) i.1F
0
20
i.2t
Delay in acquiring digital input DI2
oF Delay disabled
0.01 ÷ 9.59 (min.s) ÷ 99.5 (min.s x 10)
oF
21
i.3F
Function and function logic of digital input Pr3
See (17) i.1F
0
22
i.4F
Function and function logic of digital input Pr4 0
23
i.Et
Delay to Eco mode with door closed
oF No function
0.01 ÷ 9.59 (h.min) ÷ 99.5 (h.min x 10)
oF
