Press the Right arrow key () to move to the next option.
02/06/16
14:32:51:085
This window will show Date & Time of Fault.
Press the Right arrow key () to move to the Main Menu.
Fault 1
Note : Fault 2, Fault 3, Fault 4 and Fault 5 can be viewed in simillar manner
8.2.7 To View Error Log
Error Log
This menu is to view “Error Log”
Press the Right arrow key () to move to the next option.
Error Code : 0000
This window will show Error Code.
Press the Right arrow key () to move to the next option.
Error Log
The relay continuously keeps track on its internal hardware and the moment it detects any
failure of component, a message is displayed on LCD display. The type of error can be
checked by “Error Log” menu. This feature is very useful for giving pre information to
avoid mal operation.
Following are some of Error codes: -
Error Code Description
01 Setting Error
02 EEPROM Error
04 RTC Error
08 Crystal Error
