8.2.5 Trip Test
Trip Test
The password protected window for Trip Test.
Press the left arrow key () to move to the next option
Password = 0000
Use Inr / Dec
Editable setting
Enter the previously set password, by using the up arrow key
(+ /) or the down arrow key (- /).
Note: Default password setting is ‘0000’
Press the left arrow Key () to apply the Trip Test.
I>> : TC:0000
I> : T
This window will show High Fault, Trip Counter, IDMT Fault
and Test Trip Flag.
Press the left arrow key () to move to the next option
FAULT 1
8.2.6 Fault 1
8.2.6.1 To View – Fault 1
FAULT 1
This menu is to view “Fault 1”
Press the Right arrow key () to move to the next option.
I>> : I TC:0000
I> : I BF T
This window will show High Fault, Trip Counter, IDMT Fault
and Breaker Fail or Test Trip indication.
Press the Right arrow key () to move to the next option.
I = 1000 A
i = 000.00A
This window will show Primary & Secondary Current measured
at the time of the fault.
Please note: If Fault current is ≤ 9999 then display will show
the current in Ampere i.e. 9999A and If Fault current is ≥ 10000
then display will show the current in Kilo Ampere i.e. 10.00K
