Ashida ADR111A - Date and Time Settings; Status; To Set - DATE and TIME Settings; To View - STATUS

Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/UG
Rev No. : 04
Page No. : 101 of 127
ADR111A /
ADR211A
16 ADC Error
32 FRAM Error1
64 FRAM Error2
In case of ADC error relay will not work at all and will show directly ADC Error and relay
function will be locked.
8.2.8 STATUS
8.2.8.1 To View – STATUS
STATUS
This menu is to view “STATUS”
i.e. Software Version and
Hardware Version.
Press the Right arrow key () to move to the next option.
SWV : 02.00
HWV : 02.00
This window will show Relay Software & Hardware Version.
Press the Right arrow key () to move to the next option.
STATUS
8.2.9 DATE AND TIME SETTINGS
8.2.9.1 To Set – DATE AND TIME Settings
DATE / TIME
Password protected window for “DATE / TIME” setting i.e. Set
Hour, Set Minute, Set Second, Set Date, Set Month, and Set
Year.
Press the left arrow Key () to move to the next option.
Password = 0000
Use Inr / Dec
Editable setting
Enter the previously set password, by using the up arrow key
(+ /) or the down arrow key (- /).
Note: Default password setting is ‘0000’
Press the left arrow Key () to move to the next option.
