Ashida ADR111A - Mechanical, Back Terminal and Electrical Connection Drawings

Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/I&P
Rev No. : 04
Page No. : 39 of 127
ADR111A /
ADR211A
2.4 Mechanical, Back Terminal and Electrical Connection Drawings
2.4.1 Mechanical Dimensions without IP cover
Figure 7: Case dimensions for basic version without IP cover
Note: All dimensions in mm.
