Ashida ADR111A - To View - Relay Settings

Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/UG
Rev No. : 04
Page No. : 97 of 127
ADR111A /
ADR211A
The setting range is 2400 – 19200. (i.e.
2400, 4800,
9600,14400, 19200)
Press the left arrow Key () to move to the next option.
Hrm. Rst. = 080
Range ( 00 – 80 ) %
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the desired Hrm. Rst. can be set
The setting range is 00 to 80% in steps of 5%.. The 000 means
bypass this feature.
Press the left arrow Key () to move to the next option.
SAVE Settings?

for Save
Press the left arrow Key () to SAVE the changes.
OK
This window will flash for a moment and it will move to the Main
Menu.
RELAY SETTING
8.2.4.2 To View – Relay Settings
Relay Settings
Press the right arrow key () to move to the next option.
Unit ID = 001
This window shows the set Unit ID.
Press the right arrow key () to move to the next option.
