Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/I&P
Rev No. : 04
Page No. : 29 of 127
ADR111A /
ADR211A
Contents
2 INSTALATION AND PROCEDURE 30
2.1 Overview 30
2.2 Handling 30
2.2.1 Handling the Goods 30
2.2.2 Receipt of the Goods 30
2.2.3 Unpacking the Goods 30
2.2.4 Storing the Goods 31
2.2.5 Dismantling the Goods 31
2.3 Installation Procedure 31
2.3.1 Safe Mounting 31
2.3.2 Relay Connection and Diagram 34
2.3.3 Relay Operating Condition 34
2.3.4 Current Transformer (CT) Circuit 35
2.3.5 Insulation and dielectric strength testing 35
2.3.6 Cables and Connectors 35
2.3.7 CT/Auxiliary power/ output/ serial port connections 35
2.3.8 Rear Serial Port connection (For ADR211A only) 36
2.3.9 Power Supply Connections 37
2.3.10 Earth Connection 37
2.3.11 Current Transformers 38
2.3.12 Output Relay Connections 38
2.3.13 USB Connection (For ADR211A only) 38
2.4 Mechanical, Back Terminal and Electrical Connection Drawings 39
2.4.1 Mechanical Dimensions without IP cover 39
2.4.2 Mechanical Dimensions with IP cover 40
2.4.3 Back Terminal and Electrical connection diagrams 41
