Ashida ADR111A - To View - Relay Setting

Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/FC
Rev No. : 04
Page No. : 110 of 127
ADR111A /
ADR211A
9.3.2 To View – Relay Setting
Relay Settings
6
Unit ID = 001
I>100% t>1.000
I>>0100%
I>Normal Inv.1
I>C6 Time = 00.1
I>> Delay = 00.05
CT Sec. = 01A
CT Pri. = 0010A
Trip Cont = HR
BF Cont = HR
BF Delay = 100
Com Port = FRONT
Parity = None
Baud Rate = 09600
6
Hrm. Rst. = 000%
6 5 6 5
6 5 6 5
6 5
6 5 6 5
6 5
