11.4.3. Testing of Binary Output (Output Contact Test)
1. Set the I> = 50%, TMS=0.01, Curve Normal Inverse1.
2. Enable the BF function from the Relay Setting menu.
3. Set the Trip contact & BF contact to hand reset (HR) type from the Relay Setting
menu.
4. Apply the 1A current & operate the relay in OC & BF, so the TRIP, Alarm & BF relay
is operates.
5. After tripping, check continuity in between NO and C output contact terminal.
6. Now, press the LED Reset key to reset the contact.
7. Again check the continuity in between NO and C output contact terminal.
Binary Output Terminals Binary Output
A9 – A10 TRIP
A11 – A12
ALARM
A13 – A14
BF
