8.2 MENUS
8.2.1 Default Display
After the Power ON or when the H/W. RESET + LED RESET key is pressed, the relay will
display the following message.
Ashida Digital
Relay
This window will flash momentarily showing the following.
Relay Name : Ashida Digital Relay
Then the control will automatically move to next option.
ADR211A V–02.00
Unit ID = 001
This window will flash momentarily showing the following.
Relay Type: ADR211A_V – 02.00; Unit ID 001
Then the control will automatically move to next option.
I = 0000A
This window shows actual Primary load current as per the CT
Primary selection.
8.2.2 Main Menu Details
I = 0000A
This window shows actual Primary load current as per the CT
Primary selection.
Press the Right arrow key () to move to the next option.
i = 000.00
This window shows actual Secondary load current as per the
CT Secondary selection.
Press the Right arrow key () to move to the next option.
Measurement
The relay will display “Measurement” in Main Menu.
Press the Plus / up arrow key (+ /) to move to the next option.
Relay Settings
Password protected window for “Relay Settings’’ setting i.e.
New Password, Unit ID, I>, I> TMS, I>>, I> Curve, I>C6 Time,
I>> Delay, CT Sec., CT Primary, Trip Cont, BF Cont., BF Delay,
Com Port, Parity, Baud Rate and Hrm Rst.
