DATE / TIME
Password protected window for “DATE / TIME” setting i.e. Set
Hour, Set Minute, Set Second, Set Date, Set Month and Set
Year.
Press the Plus / Up arrow key (+ /) to move to the next option.
MEASUREMENT
This window shows the first window of Main Menu.
8.2.3 MEASUREMENT
8.2.3.1 To View – MEASUREMENT
MEASUREMENT
This menu is to view CT Primary and Secondary current as per
selection,
Press the Right arrow key () to move to the next option.
I = 0000A
This window shows actual Primary load current as per the CT
Primary selection.
Press the Right arrow key () to move to the next option.
i = 000.00
This window shows actual Secondary load current as per the
CT Secondary selection.
Press the Right arrow key () to move to the next option.
MEASUREMENTS
