ADR111A /
ADR211A
I>100% t>1.000
I>>0100%
This window shows the set Current values.
Press the right arrow key () to move to the next option.
I>Normal Inv.1
This window shows the set Curve.
Press the right arrow key () to move to the next option.
I>C6 Time = 00.1
I>> Delay = 00.05
This window shows the set I> C6 Time and I>> Delay
Press the right arrow key () to move to the next option.
CT Sec. = 01A
CT Pri. = 0010A
This window shows the set CT Secondary and CT Primary.
Press the right arrow key () to move to the next option.
Trip Cont = HR
BF Cont = HR
This window shows the set Trip Cont and BF Cont.
Press the right arrow key () to move to the next option.
BF Delay = 100
Com Port = FRONT
This window shows the set BF Delay & Com Port.
Press the right arrow key () to move to the next option.
Parity = None
Baud Rate = 09600
This window shows the set Parity and Baud Rate
Press the right arrow key () to move to the next option.
Hrm. Rst. = 000%
This window shows the set Harmonic Restrain Function.
Press the right arrow key () to move to the Main Menu.
Relay Settings
