Ashida ADR111A - Page 15

Doc ID : ADR111A_IM_01
Ref ID : ADR111A/IM/ToC
Rev No. : 04
Page No. : 15 of 127
ADR111A /
ADR211A
Section 11 : TESTING AND COMMISSIONING
Sr. No. Description Page No.
11 Testing and COMMISSIONING 123
11.1 Commissioning Test, Equipment Required 123
11.2 Checking of External Circuitry 123
11.3 Check Relay Setting 124
11.4 Relay Testing 125
11.4.1. Relay Calibration & Measurement 125
11.4.2. Pick up and Trip Test 125
11.4.3. Testing of Binary Output (Output Contact Test) 126
