Ref ID : ADR111A/IM/SS
Rev No. : 04
Page No. : 72 of 127
ADR111A /
ADR211A
This setting is used to set parity. It is important that both relay and master station are set with the same parity
setting.
17.
Baud Rate 9600 2400/ 4800/ 9600/ 14400/ 19200
This setting is used to set Baud rate. It is important that both relay and master station are set with the same
Baud rate setting.
18.
Hrm. Rst. 10 00 – 80% in step of 5%
This setting is specify the 2nd Harm Threshold value, if the level of 2nd harmonic exceeds the setting, the
over current protection will be blocked.
6.2 Date and Time setting
Sr. No Parameter Defaults setting Settings / Ranges
1.
SET Hours 00 00 – 23 Hrs in step 1.
Hour setting needed when relay is not connected to SCADA system
2.
SET Minutes 00 00 – 59 Mins in step 1.
Minutes setting needed when relay is not connected to SCADA system
3.
SET Seconds 00 00 – 59 Sec. in step 1.
Seconds setting needed when relay is not connected to SCADA system
4.
SET Date 01 01 – 31 Days in step of 1.
Date needed when relay is not connected to SCADA system
5.
SET Month 01 01 – 12 Months in step of 1.
Month needed when relay is not connected to SCADA system
6.
SET Year 01 00 – 99 Years in step of 1.
Year needed when relay is not connected to SCADA system
