7.10 Configuration
To configure the IED for this protocol, please see the Configuration chapter.
7.11 IEC-103 Protocol Mapping
Sr. No. INF Description GI TYP COT FUN
1
Semantics of INFORMATION NUMBER : System Functions in monitor direction
0 End of general interrogation - 8 10 255
0 Time synchronization - 6 8 255
2 Reset FCB - 5 3 160
3 Reset CU - 5 4 160
4 Start/Restart - 5 5 160
5 Power on - 5 6 160
Note: X under GI heading means DI Status is included in General Interrogation response.
Sr. No. INF Description GI TYP COT FUN
2 Semantics of INFORMATION NUMBER : Status & Fault indications in monitor direction
19 Trip LED X 1 1,7,9,11,12,20,21 160
22 Local parameter setting X 1 9,11,12 160
84 General Start X 2 1,7,9 160
117 Start I> X 2 1,7,9 126
103 Start I>> X 2 1,7,9 126
68 General Trip - 2 1,7 160
90 Trip I> - 2 1,7 160
91 Trip I>> - 2 1,7 160
85 50 BF x 2 1,7 160
21 Test Trip - 2 1,7 127
Sr. No. INF Description GI TYP COT FUN
3 Semantics of INFORMATION NUMBER : Measurands in monitor direction
148 I in MEA format - 9 2, 7 160
NOTE: The measurands transmitted by the relay are sent as a proportion of 1.2 times of the rated value
