WARNING!
The service department shall only be responsible for repairing and servicing the cooking hob.
Consult your specialized kitchen equipment dealer regarding re-installing the flush-mount cooking
hob.
Built-in
This unit can be connected to various discharge systems:
To a recirculation filter
After filtration through grease filters and the odour
control/fine particle filter, the extracted air is
discharged back into the room.
Required parts:
To an exhaust duct (outlet)
After filtration through grease filters, the extracted
air is discharged to the outside through a series
of ducts (to be purchased separately).
Required parts:
•• Recirculation set including ducts (HR0016)Connection piece (HD2001)
• •Exhaust air duct (HD1001) Replace combi-filter odour/fine dust (HF3010)
• Vertical / horizontal elbow
66
Installation
