VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 4 of 52
14) ETH ports: cable requirements changed from CAT5 E to CAT5 FTP or STP for EMC
compliance.
15) Cables: Pirelli replaced by Prysmian.
16) EIA 568-B updated to T568B per Telecommunications Industry Association (TIA)
17) Typos corrected, some paragraphs re-worded and additional info added for clarity.
8 1) Document Change History added.
2) QR code to ASL downloads page (back of the front cover).
3) CE declaration - RoHS Directives updated to include 2015/863/EU.
4) On-board contact input description updated to warn that earth leakage faults may be
reported by the Fire Panel using voltage-reversal method due to 100 kohms resistance to
ground. If voltage-reversal method is required, use BMB01 to avoid possible earth leakage
fault reports by the Fire Panel.
Opto-isolated changed to opto-coupled per above.
5) USB port removed from front panel images and drawings (no longer present on new units).
6) RTC Lithium battery codes corrected: from “Panasonic CR2032/BS” to “Panasonic BR2032
or Murata CR2032X”.
7) Dante™ Module changed to Dante Brooklyn II Module for clarity.
8) Technical Specification updated:
a) Residual Noise corrected from “<90 dBu (A)” to “<-90 dBu (A)”.
b) Note on on-board contacts for Fire Panel using voltage-reversal method added (see 4)
above).
c) IP Audio Protocol updated:
From:
IP Audio Protocol (with optional Network Card) ............................ 12 x ASL PMC (6 x in and 6 x out)
To:
Audio over IP (requires Network Card) .................................................................. ASL PMC format
Dante™ via optional Audinate® Brooklyn II module
Number of streams/channels in the footnote: depending on configuration 12 x PMC streams (6 x in
+ 6 x out) / 32 x Dante Rx channels.
d) Network Card USB port updated from “configuration purposes” to “diagnostic
purposes”.
e) Footnote on 24 kHz and 12 kHz DVA format updated to include the required software
version.
f) “GPS not supported on software version V4.2.0.1 (or later)” added to the footnote.
g) BOA01/BOA02 - AMP CTRL connection: ACAN DXP/DXN updated to DXP/DXN
h) Mixing data updated to V4.2.0.2:
• “optional MIX-DSP Module” removed
• Footnote added: “Mixer used for listen-in only at the time of publication of this
document.”
i) Input/Output EQ Band Reset removed as now disabled on the RDT.
j) Input EQ frequency range updated to V4.2.0.2:
From:
Low: 50 to 200 Hz / Low-Mid: 200 Hz to 20 kHz / High-Mid: 200 Hz to 20 kHz /
High: 2 Hz to 20 kHz
To:
Low: 10 to 1 kHz / Low-Mid: 20 Hz to 20 kHz / High-Mid: 20 Hz to 20 kHz /
High: 1 kHz to 20 kHz
k) Output EQ frequency range updated to V4.2.0.2:
From:
Low (Band-1): 50 to 500 Hz / Band (2-9): 20 Hz to 20 kHz / High (Band-10): 2 to 12 kHz
To:
Low (Band-1): 20 to 1 kHz / Band (2-9): 20 Hz to 20 kHz / High (Band-10): 1 to 12 kHz
l) Input/Output Peak Limiter now show range for Attack, Hold and Make Up Gain.
m) Test Tone Inputs removed as they have never been supported in the PAVA SCT and
they are no longer supported since V4.0.0.0.
n) Cross Over Filters removed as not supported.
o) Footnote on DANS limitation updated to: local outputs 1 to 4 (earlier than V3.3.2.0) /
local outputs 1 to 12 (V3.3.2.0 or later).
9) 1 GigE added to EHT5/6 ports description.
10) References to rear panel connectors corrected for BOA01 and BOA02.
12/01/21
