VIPEDIA-12 Products – Installation Guide
U-0641-0344.docx – Issue: 8 complete, approved
Page 48 of 52
Audio Input Performance
1
Input Sensitivity .................................................................................................................. -60 / -40 / -20 / 0 dBu
Input Overload .......................................................................................................................................... +20 dB
Maximum Input Level .............................................................................................................................. +20 dBu
Input Trim ............................................................................................................. –90 dB to +10 dB (1 dB steps)
Mute ....................................................................................................................................................... Click free
Phase Invert ................................................................................................................................................. on/off
Surveillance Tone Detection .......................................... Frequency Range: 20 Hz to 30 Hz / Level: -60 to 0 dB
Switchable High-Pass Filter ............................................................ Frequency: 20 to 500 Hz / Slope: 12 dB/oct
4-band Parametric EQ
Low ..................................................... Frequency: 10 to 1 kHz (1 Hz steps) / Range: ±18 dB (0.1 dB steps)
Slope: 6 dB to 12 dB/octave (shelf only) / HPF / Shelving Switch
Low-Mid .................Frequency: 20 Hz to 20 kHz (1 Hz steps) / Range: ±18 dB (0.1 dB steps) / Q:1.0 to 5.0
High-Mid ................Frequency: 20 Hz to 20 kHz (1 Hz steps) / Range: ±18 dB (0.1 dB steps) / Q:1.0 to 5.0
High ......................................... Frequency: 1 kHz to 20 kHz (100 Hz steps) / Range: ±18 dB (0.1 dB steps)
Slope: 6 dB to 12 dB/octave (shelf only) / LPF / Shelving Switch
EQ Bypass Switch ................................................................................................................................ on / off
Gate
Threshold ......................................................................................................... -60 dB to +20 dB (1 dB steps)
Attack .................................................................................................................. 0.1 to 200 ms 0.1 ms steps)
Release ................................................................................................................... 50 ms to 3 s (1 ms steps)
Hold ........................................................................................................................ 25 ms to 5 s (1 ms steps)
Gate Bypass Switch ............................................................................................................................... on/off
Compressor
Ratio ................................................................................................................................................ 1:1 to ∞:1
Threshold ......................................................................................................... -60 dB to +20 dB (1 dB steps)
Attack ................................................................................................................. 0.1 to 200 ms (0.1 ms steps)
Release ................................................................................................................... 50 ms to 3 s (1 ms steps)
Make Up Gain ....................................................................................................... 0 to +20 dB (0.1 dB steps)
Knee ..................................................................................................................... 0 to +12 dB (0.1 dB steps)
Peak / True RMS Mode ................................................................................................................. Switchable
Compressor Bypass Switch .................................................................................................................... on/off
Peak Limiter
Threshold ......................................................................................................... -60 dB to +20 dB (1 dB steps)
Attack ................................................................................................................. 0.1 to 200 ms (0.1 ms steps)
Hold ........................................................................................................................ 25 ms to 5 s (1 ms steps)
Make Up Gain ....................................................................................................... 0 to +20 dB (0.1 dB steps)
Release ................................................................................................................... 50 ms to 3 s (1 ms steps)
Limiter Bypass Switch ............................................................................................................................ on/off
Channel Fader ...................................................................................................... -90 dB to +10 dB (1 dB steps)
Chime Generator
Selectable Type .............. OFF / 1-note (660 Hz) / 2-note (660/554 Hz) / 3-note (660/554/440 Hz) / Custom
Level ................................................................................................................ -60 dB to +10 dB (1 dB steps)
1
Software version V4.2.0.2 (may be subtly different on earlier or later versions).
