20
Current Display
Auto Range
AC
Range 1:
0.000mA - 3.500mA
Resolution:
0.001mA/step
Accuracy:
 (2 of reading  0.003mA)
Range 2:
3.00 - 99.00 mA
Resolution:
0.01 mA/step
Accuracy:
 (2 of reading  0.06mA)
DC
Range 1:
0.0 A - 350.0 A
Resolution:
0.1 A/step
Accuracy:
 (2 of reading  0.3uA)
Range 2:
300 A - 3500 A
Resolution:
1 A/step
Accuracy:
 (2 of reading  2uA)
Range 3:
3000 A - 9990 A
Resolution:
10 A/step
Accuracy:
 (2 of reading  60uA)
DC Output Ripple
 4 Ripple RMS at 6 KV DC @ 3.5 mA, Resistive Load
Discharge Time
 200 ms
Maximum Capacitive
Load
DC Mode
1uF < 1KV
0.75uF < 2KV
0.5uF < 3KV
0.08uF < 4KV
0.04uF < 5KV
AC Output Wave Form
Sine Wave, Crest Factor = 1.3 - 1.5
Output Frequency
Range:
60 or 50 Hz, User Selection
Accuracy:
 1%
Output Regulation
 (1  of setting  5 volts) from no load to full load
Dwell Timer
Range:
0, 0.3 - 999.9 sec (0 = Constant)
Resolution:
0.1 sec increments
Accuracy:
 (0.1% + 0.05 sec)
Ramp Timer
Range:
AC 0.1 - 999.9 sec
DC 0.4 - 999.9 sec
Resolution:
0.1 sec increments
Accuracy:
 (0.1% + 0.05 sec)
