8.9. Interface Bus Command List
The following commands are used to toggle ON/OFF functions or menu selection items.
No other values or parameters are needed to execute these commands. However when
using commands that are usable for a certain function only (function specific), the
appropriate function select command FC, FD, FE, or FF must be executed first, to access
the parameter for that function.
Command
Function
Functio
n
Specific
FA
Test
FB
Reset
FC
ACW Function Select
FD
DCW Function Select
FE
IR Function Select
FF
GND Function Select (7704 only)
FG
ACW/DCW: Continuity On (7700 Only)
x
FH
ACW/DCW: Continuity Off (7700 Only)
x
FI
ACW: 60Hz
x
FJ
ACW: 50Hz
x
FK
ACW: Arc Fail On
x
FL
ACW: Arc Fail Off
x
FM
DCW: Arc Fail On
x
FN
DCW: Arc Fail Off
x
FO
GND: 60hz (7704 only)
x
FP
GND: 50hz (7704 only)
x
FQ
Connect On
FR
Connect Off
FS
Fail Stop On
FT
Fail Stop Off
FU
GND: Auto Offset (7704 only)
x
FV
DCW: Auto Charge-LO
x
FW
IR: Auto Charge-LO
x
F0
Enable “All Pass” SRQ
F1
Disable “All Pass” SRQ
F2
Enable “Fail” SRQ
F3
Disable “Fail” SRQ
F4
Enable “Abort” SRQ
F5
Disable “Abort” SRQ
F6
Enable “Error Command” SRQ
F7
Disable “Error Command” SRQ
F8
DCW: Ramp-HI On
x
F9
DCW: Ramp-HI Off
x
