19
3. Specifications and Controls
3.1. Model 7704 and 7700 Functional Specifications
INPUT
Voltage
100/115/200/230 VAC 10, Single Phase, User selection
Frequency
47 - 63 Hz
Fuse
15 Amp 250V fast blow internal
DIELECTRIC WITHSTAND TEST MODE
Output Rating
5 KV @ 100 mA AC,
6 KV @ 10 mA DC
Output Adjustment
Range:
0 - 5 KV AC, 0 - 6 KV DC
Resolution:
1 volt/step
Accuracy:
(2 of setting 5 volts)
Ramp-HI
12mA peak maximum, ON/OFF selectable
Charge-LO
Range:
0.0 - 350.0A DC or Auto set
HI-Limit AC
Range:
0.00 - 99.00 mA
Resolution:
0.01 mA/step
DC
Range:
0 - 9999A
Resolution:
1A/step
Accuracy:
AC or DC
(2 of setting 2 counts)
LO-Limit AC
Range:
0.000 - 9.999 mA
Resolution:
0.001 mA/step
DC
Range:
0.0 - 999.9 A
Resolution:
0.1 A/step
Accuracy:
AC or DC
(2 of setting 2 counts)
Arc Detection
Range:
1 - 9
Failure Detector
Audible and Visual
Voltage Display
Range:
0.00 - 6.00 KV Full Scale
Resolution:
10 volt/step
Accuracy:
(2 of reading 2 counts)
