4.1.4. Step Selection

Press the STEP key, the display will show the test parameters of the functions selected

for that step, i.e. the parameters of AC Withstand Voltage , DC Withstand Voltage,

Insulation Resistance or Ground Bond test. Pressing the step key again will advance to

the next step in sequence with step 1 following step 8.

Note: When the steps have been interconnected you will see an underbar character on

the display just after the step number. This indicates that the step after the active step

will run immediately after the active step is completed. The display will show:

ACW Set XXX.X s

M25-1

X.XX KV XX.XX mA

4.2. Setting Up Test Parameters

Before going to setup the Test Parameters, make sure that the Keyboard is in the Unlock

mode, then follow this procedure to setup the Test Parameters.

4.2.1. AC Withstand Test Parameter Setting

Press the ACW key and the display will show:

ACW Set XXX.X s

MXX-X X.XX KV XX.XX mA

Note: X = Numeric

ACW Set : AC Withstand Voltage test setting screen

XXX.X s : Dwell Time setting

MXX : Memory Program number

- X : Test Step number

X.XX KV : AC Output Voltage setting

XX.XX mA : AC High-Limit current setting

Use the  or  arrow keys to progress through the test parameters menu. The  key will

advance forward and  key will advance backward. The sequential forward menu items

are Voltage, HI-Limit, LO-Limit, Ramp Time, Dwell Time, Frequency, Arc Sense, Arc

Fail, Scanner Set, Offset, and Connect.

AC Output Voltage setting

Advance the menu to the Voltage parameter. The display will show:

Voltage = XXXX V

Range : 0 - 5000
