76
The following “S” commands will set test parameters on the instrument that require
numeric or alphanumeric input. To execute these commands, the appropriate function
must first be selected with the above Function Select command FC, FD, FE, or FF, to
have access to the parameter menu.
ACW
Command
Parameter
Value
Unit
SA
Voltage
0-5000
V
SB
HI-Limit
0.00-99.99
mA
SC
LO-Limit
0.000-9.999
mA
SD
Ramp Time
0.1 - 999.9
S
SE
Dwell Time
0, 0.3 - 999.9
S
SF
Arc Sense
1 - 9
-
SG
Scanner
H=Hi,L=Low,O=Open
up to 16 channels
-
DCW
Command
Parameter
Value
Unit
SI
Voltage
0-6000
V
SJ
HI-Limit
0 - 3500
A
SK
LO-Limit
0.0 - 999.9
A
SL
Ramp Time
0.4 - 999.9
S
SM
Dwell Time
0, 0.3 - 999.9
S
SO
Charge-LO
0.0 - 350.0
A
SP
Arc Sense
1 - 9
-
SQ
Scanner
H=Hi,L=Low,O=Open
up to 16 channels
-
IR
Command
Parameter
Value
Unit
SS
Voltage
100 - 1000
V
ST
Charge-LO
0.000 - 9.999
A
SU
HI-Limit
0 - 9999
M
SV
LO-Limit
1 - 9999
M
SW
Delay-Time
0, 0.5 - 999.9
S
SX
Scanner
H=Hi,L=Low,O=Open
up to 16 channels
-
