CE, cTUVus, EN50191( Models 8204, 8206, 8207), RoHS2
Input: Test, Reset, Interlock, Recall File 1 through 3
Output: Pass, Fail, Test-in-Process
Built-in Smart GFI circuit
Standard USB/RS-232, Ethernet, or GPIB.
Advanced security system with access levels and
username/password requirements
800 x 480 digital TFT LCD display
Range: 0 – 9; 0 = OFF, 1 is softest volume, 9 is loudest
volume.
Adjustments are made through the front panel. Automatic
Calibration alert function to signal operator when calibration
is due.
Bench or rack mount with tilt up front feet.
3U (W x H x D) (430 X 133 X 500 mm) (16.93” x 5.24” x
19.69”)
8 channel high voltage and high current switching matrix.
Why use the term “Counts”?
Associated Research publishes some specifications using COUNTS which allows us to provide
a better indication of the tester’s capabilities across measurement ranges. A COUNT refers to
the lowest resolution of the display for a given measurement range. For example, if the
resolution for voltage is 1V then 2 counts = 2V.
