3. Device installation and start-up
page 17 of 47 issue date 24.02.2021, release 11.1
In order to exercise the option, follow the instructions shown on the display. Detailed description of
the function is described in the PhysioGo – Technical description manual.
3.2.5.3 Miscellaneous
In order to exercise the option, follow the instructions shown on the display.
3.2.5.4 Laser applicators output power test
This function allows the user to check if the output power of laser radiation emitted by laser applicators is correct.
Laser output power test for a given applicator is only possible if it is not previously selected in a laser therapy
channel tab.
The applicator selection is performed by:
• pressing on the screen the selected field with its symbol, or
• a double press on the screen clear field with its symbol, or
• check box indication and pressing a key on the keyboard.
Laser output power measurement of point probes and scanning applicators is performed automatically, the
results are displayed on the screen. Laser output power measurement of the cluster laser applicator is possible
by the use of external radiation sensor.
During this procedure it is recommended to follow the instructions shown on the display.
To measure output laser power of the laser applicator:
Step Description
Enter the setup mode. Select Service tab, then select Laser applicators output power test.
Select the channel. Connected applicator is identified in the Accessory field.
Press Run the power measurement button.
4.
Enter the access code:
. Confirm the code by pressing key or button
5.
An instruction window depending on the type of tested applicator will appear on the screen. Follow
the steps according to the instructions.
6.
Verify the measured value.
7.
To complete the procedure, press the key or button
If measurement power is different more than ±20% from nominal power it is recommended to repeat
the measurement. The cause of incorrect indication of emitted output power may be:
• fault of the laser applicator,
• heavily soiled laser diodes or optical elements.
In case, when results of five consecutive measurements are incorrect, contact the authorized service.
3.2.6 Statistics
3.2.6.1 Info
Provides information about the version of the unit, software, interface and software build date.
3.2.6.2 Unit statistics
Provides information about the number of treatment procedures performed. Statistics can be deleted. If you
want to delete statistics, press Delete programs counters button.
3.2.6.3 Accessories statistics
Provides information about the connected accessories.
