4. Unit operation
page 27 of 47 issue date 24.02.2021, release 11.1
Symbol Description
1 Current name / Program name
2 Output circuits amplitude identifiers
3 Indication of the treatment elapsing time
4 Information field
5 Tab field – channel 1
Figure 4.5. Screenshot sample view for single circuit electrotherapy A and B
Figure 4.6. Screenshot sample view for electrotherapy sequences
Symbol Description
1 Indication of the treatment elapsing time and sequence step
