4.2 MEASUREMENTS ON THE DISPLAY
The measures shown on the display are listed below. The display management for the
measures, is described in the section 4.3.3.
OUTPUT Description
OUTPUT VOLTAGE
= RMS value of the UPS output voltage
OUTPUT FREQUENCY
= Value, in Hertz, of the frequency of the output voltage
OUTPUT CURRENT
= RMS value of the output current
LOAD %
= Percentage of load calculate with reference to the rated
load in kVA
BYPASS Description
BYPASS VOLTAGE
= RMS value of the bypass input voltage
BYPASS FREQUENCY
= Value, in Hertz, of the frequency of the bypass voltage
INVERTER Description
INVERTER VOLTAGE
= RMS value of the inverter output voltage (measured
upstream the inverter static switch)
INVERTER FREQUENCY
= Value, in Hertz, of the frequency of the inverter voltage
AC/DC Description
AC/DC VOLTAGE
= RMS value of the rectifier output voltage (DC bus)
BATTERY Description
BATTERY VOLTAGE
= RMS value of the battery voltage
BATTERY TYPE
= Value, in Ah, of the battery nominal capacity
BATTERY CURRENT
= Battery current during discharge mode
BATTERY AUTONOMY
= Value, in minutes, of the calculated autonomy time
BATTERY AUTONOMY %
= Value, in %, of the calculated autonomy (remaining
capacity)
