5 GENERAL TECHNICAL DATA
5.1 TECHNICAL DATA SHEETS
5.1.1 GENERAL INFORMATION
UPS POWER (kVA) 20 30 40 60 80
UPS typology ON LINE – Double Conversion
Nominal output power @ P.F. 0,8 (kVA) 20 30 40 60 80
Nominal output power @ P.F. 1 (KW) 16 24 32 48 64
Efficiency AC ÷ AC (%)
>90 >90 >90 >90 >90
Heat dissipation at nominal load and voltage:
-KW
-Kcal
1,78
1531
2,67
2296
3,55
3053
5,33
4584
7,11
6115
UPS ambient temperature (°C)
0÷40
BATTERY ambient temperature (°C)
0 ÷ +25
UPS storage temperature (°C)
-10 ÷ +70
BATTERY storage temperature (°C)
-10 ÷ +60
Relative humidity non condensing (%) <95
Altitude (mt) <1000 (Above Sea Level)
Power de-rating for altitude > 1000mt According “EN62040-3”
Ventilation FORCED
Requested cooling air volume (mt3/h) 700 800 1200 1500 2100
Audible noise level (according EN 50091) <58dB <60dB
Standard battery type lead acid (N° cells) 192
Storage time of battery without recharge (at 25°C) 3 months
Protection degree IP 20
EMC Compatibility According “EN 50091-2”
Paint RAL 5026 Met.
RAL 9006 Met.
Accessibility Front and top access for service
Static load without battery (Kg/m2) 610 628 730 844 958
Input/output cable connection Bottom side
Transport Base provided for forklift handling
Transport mechanical stress According “EN62040-1”
Design standard According “EN62040-1”
Free contact interface On request
Serial communication interface RS232-RS485
Parallel configuration To increase output power up to 4
UPS or 3+1 redundant
