OM226142 rev C
29
5.1.2 RECTIFIER
UPS POWER (kVA) 20 30 40 60 80
Nominal Input Voltage (Vac)
380÷415 +/- 10% (Selectable)
Input Frequency (Hz) 50-60 +/- 5%
Input Power Factor (@ 380Vac) >0,8
DC Voltage Accuracy (%) +/- 1
DC Voltage Ripple (With battery connected) (% rms) <2
THD rejected into the mains (%) <32
Battery Recharging Characteristic IU (DIN 41773)
Temperature Battery Voltage Compensation On Request
Maximum Battery Recharging Current
(@ nominal load) (A)
10
10
15
20
20
Rectifier Bridge Type Three Phase Full bridge rectifier
Input protection Fast fuses
Nominal Current Absorbed from Mains
(@ nominal load and Battery in floating) (A)
34
50
66
100
133
Maximum Current Absorbed from Mains
(@ nominal load and max. recharging current) (A)
42
60
79
116
149
