Astrid UPS HALLEY/E Series - Spare Parts List (continued); Spare Parts for HALLEY;E 60 kVA

OM226142 rev C
53
7.4 SPARE PARTS FOR HALLEY/E 40KVA
7.4.1 Level 1
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
FN001_6.3X32 AUXILIARY FUSES 6,3x32 1A
2
FN1.6_5X20 FANS FUSES 5x20 1,6A
4
FN100URGX58 RECTIFIER FUSES 14x51 100A URGB 3
3
FN100URGX58 STATIC BYPASS POWER FUSES 14x51 100A URGB 3
1
7.4.2 Level 2
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
PB001 POWER SUPPLY HV PS-HV 1
1
PB003+PB011+PB012
+PB014
INVERTER STATIC SWITCH CONTROL
LOGIC 1/F
I/S-CL 1
1
PB010 SCR BRIDGES FIRING 1/F SCRSF-1F 3
2
PB047 FREE CONTACT INTERFACE FCI 1
1
PB013 IGBT DRIVE ID 3
2
PB004 INVERTER ACTUAL VALUE 3/F INV-AV-3F 1
1
PB005 VOLTAGE REFERENCE 3/F VOLT-REF-3F 1
1
PB116
RECTIFIER CONTROL LOGIC POWER
SUPPLY
SYNC-12 1
1
PB117 RECTIFIER CONTROL LOGIC RCLS-1 1
1
PB121-122 SYSTEM CONTROL PANEL E SCP-E 1
1
7.4.3 Level 3
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
SCRD132A12V RECTIFIER BRIDGE POWER MODULE 132A 1200V 3
2
IGD200A12V IGBT INVERTER POWER BRIDGE 200A 1200V 3
2
SCRD56A12V INVERTER STAT.SWITCH THYRISTORS 56A 1200V 3
1
SCRD91A12V BYPASS STAT.SWITCH THYRISTORS 91A 1200V 3
1
VA150D230V FAN
φ 150mm 230Vac
5
3
CC2200U500V DC CAPACITORS 2200uF 500V 2200uF 500Vdc 4
2
CA200U250V AC FILTER CAPACITORS 200uF-250V 200uF 250Vac 3
1
7.4.4 Additional spares
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
PB046 INPUT/OUTPUT RFI FILTER EMIF-3F 2
1
PB040 BATTERY RFI FILTER EMIF-B 1
1
TAH0300A HALL EFFECT CURRENT TRANSFORMER 300A 2000:1 1
1
ACM7002 CURRENT TRANSFORMER 80-130-160/0,1A 3
1
