Astrid UPS HALLEY/E Series - Spare Parts List (continued); Spare Parts for HALLEY;E 40 kVA

OM226142 rev C
52
7.3 SPARE PARTS FOR HALLEY/E 30KVA
7.3.1 Level 1
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
FN001_6.3X32 AUXILIARY FUSES 6,3x32 1A
2
FN1.6_5X20 FANS FUSES 5x20 1,6A
2
FN100URGX58 STATIC BYPASS POWER FUSES 14x51 100A URGB 3
1
FN063_GGX58 BATTERY POWER FUSES 22x58 63 gG 2
2
7.3.2 Level 2
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
PB001 POWER SUPPLY HV PS-HV 1
1
PB003+PB011+PB012
+PB014
INVERTER STATIC SWITCH CONTROL
LOGIC 1/F
I/S-CL 1
1
PB009 SCR BRIDGES FIRING 3/F SCRSF-3F 1
1
PB013 IGBT DRIVE ID 3
2
PB004 INVERTER ACTUAL VALUE 3/F INV-AV-3F 1
1
PB005 VOLTAGE REFERENCE 3/F VOLT-REF-3F 1
1
PB113 SCR FIRING FIR-91 1
1
PB114
RECTIFIER CONTROL LOGIC POWER
SUPPLY
PRCH 1
1
PB115 RECTIFIER CONTROL LOGIC LOOP 1
1
PB121-122 SYSTEM CONTROL PANEL E SCP-E 1
1
7.3.3 Level 3
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
SCRD91A12V RECTIFIER BRIDGE POWER MODULE 91A 1200V 3
2
IGD100A12V IGBT INVERTER POWER BRIDGE 100A 1200V 3
2
SCRD56A12V INVERTER STAT.SWITCH THYRISTORS 56A 1200V 3
1
SCRD56A12V BYPASS STAT.SWITCH THYRISTORS 56A 1200V 3
1
VA150D230V001 FAN
φ 150mm 230Vac
2
2
CC2200U500V DC CAPACITORS 2200uF 500V 2200uF 500Vdc 3
2
CA200U250V AC FILTER CAPACITORS 200uF-250V 200uF 250Vac 3
1
7.3.4 Additional spares
ASTRID CODE DESCRIPTION TYPE / VALUE
QUANTITY
Inst. Rec.
PB120 INVERTER BRIDGE POWER CARD IBPC-7 1
2
PB046 INPUT/OUTPUT RFI FILTER EMIF-3F 2
1
TAH0100A HALL EFFECT CURRENT TRANSFORMER 100A 1
1
ACM7001 CURRENT TRANSFORMER 30-60/0,1A 3
1
