OM226142 rev C
31
5.2 INSTRUCTIONS FOR INSTALLATION
5.2.1 Receipt of the UPS
When the UPS is received, please attend immediately to its unpacking and carry-out an
accurate visual check to be sure that the equipment has not been damaged during
transport.
IMPORTANT
In case of objections relating to damage incurred during transport these must be
immediately notified to the transportation company after receipt of the equipment.
When the UPS is not installed immediately it must be stored carefully in vertical position,
as indicated on the packing and conserved in a dry and sheltered room in its box so that it
is protected from dust.
5.2.2 Handling of the UPS
Before positioning the UPS, in order to avoid risks of turnover, it’s recommended to move
the system on the wood pallet on which the UPS is fixed.
Before the positioning in the final location, remove the UPS from the pallet.
The UPS can be lifted and handled using a pallet truck or a forklift.
The UPS can be handled only after having taken-off (manually), the lower front panel, so
that a pallet truck or a forklift can be inserted (see picture 21).
The UPS technical data are shown on a label fixed on the internal side of the front door.
Picture 21 – Handling of the UPS
