2-19
ASUS ESC4000A-E10
11. From the back of the Cache Vault Power Module clip holder, push the Cache Vault
Power Module clip holder out of the server system.
1
2
12. Align the three screw holes on the Cache
Vault Power Module clip to the three
screw holes on the Cache Vault Power
Module clip holder, then secure the clip
with the bundled three (3) screws and
three (3) bundled nuts.
13. Align and install the Cache Vault Power
Module into the Cache Vault Power
Module clip.
